The 10.1″ Android POE Wall Mount Tablet supports built-in interfaces to support POE (48V input 802.3af) direct line that supplies both data and power through a CAT 5 cable. The unit also supports a dc-in adapter with an ethernet LAN connection via built-in RJ45 for those installations which do not have PoE support. The wall unit supports high resolution IPS screen with a resolution of 1280×800 and a brightness intensity of 350 nits. The unit supports a number of interfaces ( optional ) that include RS 232, RJ 485, and GPIO. There is also an optional front proximity sensor for detecting motion and triggering various activities such as waking up automatically from sleep mode. The 10.1″ Android POE Wall Mount Tablet also has support for front NFC reader that is based on 13.56MHz Mifare standard. This allows you to swipe your NFC cards for authorization to access the application.
You can install third-party Meeting Room booking and scheduling applications such as Goget’s Meeting Room Display or Robin’s Meeting Room Booking app.
Tablet Key Features
- Display: 10.1″ inch IPS 1280*800 10 Points Capacitive Touchscreen, Wide Visual Angle
- System: Android 4.2.2
- CPU: Allwinner Dual-Core cortex-A7,1.2Ghz
- Storage: 1GB DDR3 Ram, 4GB Nand Flash
- Built-in POE 802.3af 48V Standard ( Optional RJ45/DC-In)
- Front Camera
- Front Proximity Motion Sensor
- Boot-up on power on
- Auto Power-on feature
- Rooted Permission
- Back Interface USB with Optional ( Serial Port/ GPIO)
Specifications
| General | |
| Operating System: | Android 4.2.2 |
| Display Technology: | IPS 10 Points capacitive touch screen |
| Screen Size: | 10.1 inch |
| Max Resolution: | 1280*800 |
| CPU Type: | Allwinner Dual-Core cortex-A7,1.2Ghz |
| CPU Manufacturer: | Allwinner |
| CPU Speed: | 1.2GHZ |
| RAM / Technology: | DDR3 |
| RAM Installed Size: | 1GB |
| Hard Drive Type: | 4GB NAND FAST FLASH |
| PCMCIA Expansion: | T-FLASH(Support 16G MAX) |
| Camera: | Dual Cam 2.0MP (back)+0.3MP (front) |
| HDMI: | 1080P |
| 3G: | supports External Modem |
| Motion-Sensor: | Front Proximity Motion Sensor (Optional) |
| Audio: | Built in stereo speakers/Built in Microphone |
| Software Support: | Youtube/Facebook/Twitter/MSN/Android market/Skype/Calculator/Google Mail/Google maps/iReader/Quick Office |
| Language: | Multi-language support |
| Battery Type: | 1000mAh (Optional backup) |
| Battery / Run Time(up to): | about 2 hours |
| Power Supply | 9V-24V |
| Voltage required: | 100/240V |
| Bluetooth | Bluetooth v2.1+EDR/Bluetooth 3.0/3.0+HS/4.0 |
| NFC | 13.56MHz Mifare. Optional |
| Item Dimensions/ W*D*H: | 277*163*14mm |
| Shipping Dimensions/ W*D*H: | 23*18*7CM |
| Net Weight: | 600G |
| Input/Output Connectors | |
| Ports: | 1 x USB 1 x Micro Sd Card slot 1 x DC jack 1 x Earphone jack |
| Communications | |
| Networking / Data Link Protocol: | Fast Ethernet
POE 802.3af (optional) |
| Wireless Connection: | WIFI |
| Wireless Protocol: | 802.11 b/g |
| Serial Interfaces | RS 232, RJ 485 and GPIO |
| Support Format | |
| Video: | AVI/RM/RMVB/MKV/WMV/MOV/MP4/DAT(VCD format)/VOB(DVD format)/PMP/MPEG/MPG/FLV/ASF/TS/TP/3GP/MPG |
| Audio: | FLAC/APE/WAV |
| Picture: | JPG/BMP/PNG/GIF |
| Ebook: | WORD/EXCEL/PPT/PDF/TXT/CHM/HTML |
Also included in the package:
- 1 x Tablet PC
- 1 x Wall Mount
- 1 x Charger
- 1 x Earphone
- 1 x USB Cable
- 1 x English User’s Manual
